Lamborghini Gallardo
Technical data sheet
Chassis and body:
Frame : Structural aluminium spaceframe, based on aluminium extruded parts
welded to aluminium casted joint elements.
Body : Aluminium with thermoplastic "hang on" parts.
Suspension : Double wishbones front and rear suspension system, anti-roll bar,
anti-dive and anti-squat,"self adjusting" FSD dampers
ESP Full ESP system with ABS, ASR and ABD
Brakes Power vacuum, aluminium alloy calipers: 8 cylinders front caliper and 4
cylinders rear caliper.
Ventilated discs: Ø 365 x 34 mm front - Ø 335 x 32 mm rear
Steering Power-assisted rack and pinion
Tyres (front - rear) Pirelli Pzero 235/35 ZR 19 - 295/30 ZR 19
Wheels (front - rear) Aluminium alloy: 8.5" x Ø 19" - 11" x Ø 19"
Kerb-to-kerb turning circle 11.5 m
Mirrors External mirror with electrical closing system and heating system,
internal mirror with anti-blinding system
Rear spoiler Electronically controlled
Airbags Front "dual stage" driver and passenger airbags, side "head-thorax"
airbags
Engine:
Type 10 cylinders V 90°, DOHC 4 valves, 18° crankpin offset
Displacement 4961 cc
Bore and Stroke Ø 82.5 mm x 92.8 mm
Intake system Variable geometry
Valve gear chain driven, intake and exhaust continuously variable valve timing,
electronically controlled
Compression ratio 11:1
Maximum power 367 kW (500 hp) at 7800 rpm
Maximum torque 510 Nm at 4500 rpm
Emission control system Catalytic converters with lambda sensors
Cooling system Two water radiators + gearbox oil cooler + engine oil cooler
Engine management system Electronic Lamborghini L.I.E., with individual static
ignition,
multipoint sequential fuel injection, Drive-by-Wire system, OBD
system
Lubrication system Dry sump
Drivetrain:
Type of transmission Permanent 4-wheel drive with viscous traction system
6 speed + reverse
As optional, robotized sequential E-gear system with actuation by
paddles on the steering column
Clutch Double plate Ø 215 mm
Rear differential 45% limited slip
Front differential Slip limitation by ABD function
Capacities:
Fuel Tank 90 litres
Engine oil 10 litres
Engine coolant 20 litres
Performance:
Top speed 309 km/h
Dimensions:
Wheelbase 2560 mm
Overall length 4300 mm
Overall width 1900 mm
Overall height 1165 mm
Track (front - rear) 1622 mm - 1592 mm
Weight ("dry"-no fuel) 1430 kg
Weight distribution (front - rear) Front 42% - rear 58%
